Network Switch Mini 5Ports Switch Ethernet 1000Mbps/100Mbps Gigabit High Performance Smart Switcher RJ45 Hub Internet Injector

Introduction:

These unmanaged switches are Fast Ethernet switch designed for high forwarding network environment such as school, family, SMEs and mini monitoring. It has 5 port 10/100Mbps or 10/100/1000Mbps adaptive Ethernet ports. All ports support wire-speed forwarding and the data rate is up to 100Mbps or 1000Mbps. There is 4K lightning protection to ensure smooth and stable operation. Auto MDI/MDIX is also available. No configuration is required; it will instantly operate as soon as you power it up.

Features:

5*100M or 5*1000M Ethernet port with auto-negotiation function

Support 100M/1000M speed rate,MDI/MDIX

Support IEEE802.3x Flow control and back pressure control

Each port has the complete LED Indicator light

Each port supports wire-speed switching ,64~1518 frame length can reach the wire speed

Support multicast to avoid network congestion

Support 5-16V voltage input

Support 4K lightning protection of whole device.

Require no configuration and will instantly operate as soon as you power it up

Use low-power consumption chips,only 2.5W in full load conditions

Specification:

• Standards：
• IEEE802.3 10Base-T
• IEEE802.3u 100Base-TX/FX
• IEEE802.3x Flow control
• Ethernet Port：
• Connector: RJ45
• Data Rate: 10/100M or 10/100/1000M
• Distance: 100m
• UTP Type: UTP-5E or higher level
• Performance：
• Processing Type: Store and Forward
• Transmission Mode: half/full-duplex with auto-negotiation function
• MAC Table Size: 1K
• Buffer Space: 448K
• Back bandwidth: 1G
• Time Delay: ＜150μs
• Power：
• Power type: external power supply
• Input Voltage: AC100V～240V 50/60Hz
• Connector: DC Socket
• Working Voltage: 5V
• Power Consumption: 1.8W～4W
• Environment：
• Storage Temperature: -40～70℃
• Operating Temperature: -10～55℃
• Relative Humidity: 5-90% ( no condensation)
• Physical Characteristics：
• Dimension: 100×52×28mm
• Weight: 0.30kg
• Color: Black
