150W 16 Port Power Over Ethernet Switch + 2TP + 1SFP PoE Network Switch

150W 16 Port Power Over Ethernet Switch + 2TP + 1SFP PoE Network Switch



Production Description





1) Up to 30W of Power on

2) Extender 250M 1-16 port

3) IEEE 802.3af/at

4) Compatible With All IEEE 802.3af/at or Legacy

5) Safe: Low Power Devices Receive Only the Power They Need

6) Safe and Reliable Power to WLAN Access Points

7) Automatic Detection and Protection of Non–standard Ethernet Terminals

8) Supports 10/100 Base-T applications

9) Compact Design Fits Easily in WLAN Access

10) Plug-and-Play no configuration required

11) Internal power supply

12) Easy installation and maintenance

13) Save up to 83% power with Green Technology

14) Complies to IEEE 802.3af   PoE standard and is backward



Product Overview



Modern business networks are used for increasingly diverse applications – traditional data streams, VoIP voice traffic, video output from digital security cameras and remote control devices to name a few. The range of devices attached to today’s converged network often need to be supported not just in terms of data – equipment such as VoIP IP telephones and Wireless Access Points frequently need to be powered in physical locations where mains power is not available or difficult to deliver. Providing power to such devices via an Ethernet UTP cable is an elegant and easy to implement solution.



 PoE technology conveniently eliminates the need to install networked devices, such as PSE1816GSR  IP cameras and access points, near a power outlet, thereby reducing equipment and installation costs.

compatible to IEEE802.3af/at. It can power both existing

10/100Base-T network devices Wi-MAX and wireless

IEEE 802.11n access points.





Hardware Specification



10/100Mbps Copper Ports



16 10/ 100Base-TX RJ-45 Auto-MDI/MDI-X ports



1000Mbps Copper Ports



2 10/100/1000Mbps RJ-45 Auto-MDI/MDI-X ports



SFP/mini-GBIC Slots



2 1000Base-SX/LX, shared with Port-17~Port-18



Switch Architecture



Store-and-Forward



Switch Fabric



12.8Gbps / non-blocking



Switch Throughput



5.36Mpps @64Bytes





Address Table



8K entries



Share Data Buffer



512Kbytes



Maximum Frame Size



9K Bytes





Flow Control



Back pressure for Half-Duplex

IEEE 802.3x Pause Frame for Full-Duplex





LED



Power (yellow )

10/100 LINK / ACT (Green)

1000  ACT(Green);1000 LINK(yellow)







Reset Button



< 5 sec: System reboot

> 5 sec: Factory Default



Dimension (W x D x H)



293 x 165 x 44 mm, 1U height



Weight



2kg



Power Requirement



100~160V AC, 50-60 Hz



Power Consumption / Dissipation





150 Watts maximum /510 BTU/hr maximum



Power over Ethernet



PoE Standard



IEEE 802.3af/at Power over Ethernet / PSE



PoE Power Supply Type



End-Span



PoE Power Output

Per Port 52V DC, 350mA~600ma . Max. 30 Watts



Power Pin Assignment



1/2(+), 3/6(-)



PoE Power Budget



135 Watts



Max. number of Class 3 PD



9























Standards Conformance









Standards Compliance



IEEE802.3:10Base-T IEEE802.3u: 100BaseTX

IEEE802.3z:1000Base-SX/LX IEEE802.3ab:1000Base-T IEEE802.3af/at:

Power over Ethernet



Environemmental



Operating

Temperature: 0 ~ 50 Degree C Relative Humidity: 20 ~ 95%



Storage

Temperature: -10 ~ 70 Degree C

Relative Humidity: 20 ~ 95% (non-condensing)
